Schulz 50 Cfm Refrigerated Compressed Air Dryer, 10hp & 15hp Compressor

Details

Schulz ADS 50 Non-Cycling Refrigerated Compressed Air Dryer (50 CFM 115V 1-Phase)

1 YEAR WARRANTY.

Excellent Performance

Even where ambient & inlet temperatures are elevated

Nominal air pressure of 100 PSI; 232 PSI maximum

Energy Efficient Sizing

Matches the compressor’s displacement, saving energy

Electronic Controller

Digitally shows temperature & dew point

Controls the drain valve through a timer

Controls the condenser fan through a probe

High-Efficiency Compressor

Circulates the refrigerant through the system

Totally New Design

Delivers high dependability & low power consumption

Quick disconnect automatic drain valve doesn’t need special tools

Requires a 115V, single phase circuit

Environmentally Friendly Refrigerant

R134a is effective & easier on the environment

Technical Features

Model

ADS 50

Flow (CFM)

50

Rated Pressure (PSI)

175

Maximum Pressure (PSI)

232

Connection (in)

1/2″ NPT-F

Voltage (V)

115

Refrigerant Fluid

R134a

Frequency (Hz)

60

Phase

Single

Nominal Voltage (A)

3.4

Dimensions (HxWxL in)

19 x 15 x 19

https://schulzproducts.com/wp-content/uploads/2018/05/DRYER-SCHULZ.pdf
